 Home » OlderGeeks.com Freeware Downloads » Hardware Testing and Diagnostics » HE - Hardware Read and Write Utility v1.21.1.20
File - Download HE - Hardware Read and Write Utility v1.21.1.20
Description

Always scroll to the bottom of the page for the download link.
We don't believe in fake/misleading download buttons and tricks. The link is always in the same place.



HE - Hardware Read and Write Utility v1.21.1.20

HE - Hardware Read and Write utility is a powerful utility for hardware engineers, BIOS engineers, driver developers, QA engineers, performance test engineers, diagnostic engineersÖ etc.

This utility access almost all the computer hardware, including PCI (PCI Express), PCI Index/Data, Memory, Memory Index/Data, I/O Space, I/O Index/Data, Super I/O, DIMM SPD, CPU MSR Registers, S.M.A.R.T monitor, HDD physical sector , ATA Identify Data, ACPI Tables Dump, ACPI AML Code Disassemble, Embedded Controller, USB Information, SMBIOS Structures, PCI Option ROMs and MP Configuration Table.

Itís a Windows base utility support Win7 / Win8 / Win8.1 / Win10.

This utility comes with ABSOLUTELY NO WARRANTY, it allows you to modify hardware settings, this may damage your system if something goes wrong. Author will not take any responsibility about that, you are on your own risk.

How to use


To run this program with all functions, you need HE.EXE, HE.INI.

To run this program for minimum functions (PCI (PCI Express), PCI Index/Data, Memory, Memory Index/Data, I/O Space, I/O Index/Data, CPU MSR Registers, Physical Disk Sectors, ATA Identify Data, S.M.A.R.T Monitor, ACPI Table Dump, ACPI AML Code Disassemble, Embedded Controller, USB Information, SMBIOS Structures, PCI Option ROMs, MP Configuration Table), you need HE.EXE only, but some information will not be displayed, such as PCI vendor name...

For Super I/O, HE will load the [SUPERIO] section in initial file HE.INI, and auto detect the system entry by entry, once the detection routine return success, the Super I/O function will be available to use, user may add new super I/O entries in HE.INI.

For DIMM SPD functions, HE will load the [SMBUS] section in HE.INI, same as the [SUPERIO] section, program will detect the chipset to find out the SM bus controller, and the algorithm provided by this section support the DIMM SPD functions. Also, user may add new entries to HE.INI to support new chipsets.

By the way,HE also provide system report function,it can save almose all computer hardware configuration and software environment include environment variables,installed drivers information,installed software information,process information,system event log information,logical partition information,service information and so on.


V1.21.1.20
January,2021

1. Add Pci Information refresh Button.

2. Add SMBIOS Type11 Currect configured memory frequency & voltage in SPD page.

3. Improve USB function.

4. Update Pci Ids database 2021.01.11.

5. Add Intel AVX512F/SHA instructions checking in CPU page.































Continue below to download this file.


Downloads Views Developer Last Update Version Size Type Rank
423 687 Faintsnow <img src="https://www.oldergeeks.com/downloads/gallery/thumbs/HardwareReadWrite1_th.png"border="0"> Jan 19, 2021 - 12:51 1.21.1.20 3MB ZIP 5/5, out of 2 Votes.
